| DN | INCH | L (mm) Full Length | Ø D (mm) | D (mm) | K (mm) | B | N | Ø | NB |
Working Pressure PN |
||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ΔL Axial Motion | ||||||||||||
| 30 (mm) | 45 (mm) | 60 (mm) | ||||||||||
| 25 | 1" | 110 | - | - | 115 | 43 | 85 | 18 | 4 | 14 | 18 | 16 |
| 32 | 1 1/4" | 110 | - | - | 140 | 43 | 100 | 18 | 4 | 18 | 18 | 16 |
| 40 | 1 1/2" | 120 | 150 | - | 150 | 49 | 110 | 18 | 4 | 18 | 22 | 16 |
| 50 | 2" | 120 | 150 | - | 165 | 61 | 125 | 18 | 4 | 18 | 36 | 16 |
| 65 | 2 1/2" | 120 | 150 | 180 | 185 | 77 | 145 | 18 | 4 | 18 | 58 | 16 |
| 80 | 3" | 120 | 150 | 180 | 200 | 89 | 160 | 20 | 8 | 18 | 78 | 16 |
| 100 | 4" | 120 | 150 | 185 | 220 | 115 | 188 | 20 | 8 | 18 | 124 | 16 |
| 125 | 5" | 125 | 155 | 190 | 250 | 140 | 210 | 22 | 8 | 18 | 180 | 16 |
| 150 | 6" | 130 | 155 | 200 | 285 | 169 | 240 | 22 | 8 | 22 | 252 | 16 |
| 200 | 8" | 150 | 190 | 230 | 340 | 220 | 295 | 24 | 12 | 22 | 430 | 16 |
| 250 | 10" | 165 | 205 | 245 | 405 | 274 | 355 | 26 | 12 | 26 | 660 | 16 |
| DN | PN | L(mm) Full Length | Ø D (mm) | b (mm) | k (mm) | Ø d x n | Etki Alanı | ||
|---|---|---|---|---|---|---|---|---|---|
| ΔL Axial Motion | |||||||||
| 30 (mm) | 45 (mm) | 60 (mm) | |||||||
| 40 | 16 | 120 | 150 | - | 150 | 18 | 110 | 18x4 | 23 |
| 50 | 16 | 120 | 150 | - | 165 | 18 | 125 | 18x4 | 37 |
| 65 | 16 | 120 | 150 | 180 | 185 | 18 | 145 | 18x4 | 58 |
| 80 | 16 | 120 | 150 | 180 | 200 | 20 | 160 | 18x8 | 78 |
| 100 | 16 | 120 | 150 | 185 | 220 | 20 | 180 | 18x8 | 126 |
| 125 | 16 | 125 | 155 | 190 | 250 | 22 | 210 | 18x8 | 185 |
| 150 | 16 | 130 | 155 | 200 | 285 | 22 | 240 | 22x8 | 266 |
| 200 | 16 | 150 | 190 | 230 | 340 | 24 | 295 | 22x12 | 440 |
| 250 | 16 | 165 | 205 | 245 | 405 | 26 | 355 | 26x12 | 677 |
| 300 | 16 | 165 | 215 | 245 | 460 | 28 | 410 | 26X12 | 952 |
| 350 | 16 | 170 | 215 | 255 | 520 | 30 | 470 | 26X16 | 1140 |
| 400 | 16 | 170 | 230 | 255 | 580 | 32 | 521 | 30X16 | 1470 |
| 450 | 16 | 185 | 235 | 270 | 640 | 32 | 585 | 30X20 | 1841 |
| 500 | 16 | 195 | 235 | 285 | 715 | 34 | 650 | 33x20 | 2258 |
| 600 | 10 | 190 | 245 | 240 | 780 | 28 | 725 | 30x20 | 3220 |
| 700 | 10 | 190 | 225 | 240 | 895 | 30 | 840 | 30x24 | 4362 |
| 800 | 10 | 190 | 225 | 230 | 1015 | 32 | 950 | 33x24 | 5691 |
| 900 | 10 | 190 | 210 | 255 | 1115 | 62 | 1050 | 33x28 | 7182 |
| 1000 | 10 | 190 | 210 | 205 | 1230 | 34 | 1110 | 36x32 | 8802 |
